By: Dominik Hoefling - 10/2/2014
Now that you’ve finished Part I & Part II of my three part Managed Availability blog series, I will now provide some information about local .xml monitoring files and overrides of Managed Availability.
Local Managed Availability .xml monitoring files
Some HealthSets, such as the FEP HealthSet are local .xml files. Because FEP is the Forefront Endpoint Protection service, some of you may want to disable this HealthSet on the servers, because there is no use for it.
Browse to %ExchangeInstallationPath%\Microsoft\Exchange\V15\Bin\Monitoring\Config, search for FEPActiveMonitoringContext.xml and open the file with an editor, such as Notepad.
Change line 12 by replacing Enabled = True to Enabled = False
Restart the Microsoft Exchange Health Management service on the server where you modified the .xml file.
With overrides, you can change the Managed Availability monitoring thresholds and define you own settings when Managed Availability in case of errors should take action.
There are two kinds of overrides:
- Local overrides: are used to customize a component on a specific server or on components which aren’t globally available. For example, if you are running multiple datacenters and would like to change only server components on a specific location for individual monitoring. Local overrides are managed with the *-SetMonitoringOverride set of cmdlets. They are stored in the registry under HKEY_LOCAL_MACHINE\SOFTWARE\Microsoft\ExchangeServer\v15\ActiveMonitoring\Overrides\ and are automatically updated every 10 minutes. The Microsoft Exchange Health Management service reads the changes in the registry path above.
- Global overrides: are used to customize a component for a whole Exchange organization. They are managed with the *-GlobalMonitoringOverride set of cmdlets. Global overrides are stored in Active Directory:
CN=Overrides,CN=Monitoring Settings,CN=FM,CN=Microsoft Exchange,CN=Services,CN=Configuration,DC=Xiopia,DC=local
You can set overrides for specific Exchange versions, such as CU6 with version “15.0.995.29”. This setting will then be effective until the Exchange version changes and will be set with the ApplyVersion parameter.
The other method is to set overrides for a specific timeframe. With Exchange 2013 CU6 you can set overrides for a maximum of 365 days with the Duration parameter.
Managed Availability and server reboots
Responders only execute in the event that a monitor is marked in an Unhealthy state and will try to recover that component. Managed Availability provides multi-stage recovery actions:
